最大耐压 |
40公斤 |
|
接口尺寸 |
1/8 1/4 3/8 |
|
最大转速 |
100RPM |
|
安装方式 |
可选法兰配合 |
|
工作溫度 |
-18° C to 105° C |
|
可加电气滑环 |
可选 |
|
可选项 |
其它可选旋转编码器,光纤,电气滑环 |
.jpg)
.jpg)
| Part | RRU-QT-0401-H | RRU-QT-0402-H | RRU-QT-0403-H |
| A | 156mm | 175mm | 183mm |
| B | 56mm | 65mm | 66mm |
| C | 22mm | 24mm | 26mm |
| D | G1/8 | G1/4 | G3/8 |
| E | 25mm | 30mm | 30mm |
| F | 12.5mm | 15mm | 15mm |
| G | 90mm | 123mm | 123mm |
| H | 78mm | 100mm | 100mm |
| J | 6mm | 8mm | 10mm |
| K | 20mm | 20mm | 20mm |
| L | 80mm | 114mm | 114mm |
| M | 30mm | 30mm | 30mm |
| N | 4 | 4 | 4 |
| P | M4 | M4 | M4 |
| Q | M8 | M10 | M10 |
| R | M12 | M16 | M16 |
.jpg)
| PART | A | B |
| RRU-QT-0401-H-C6..56-C | 40mm | 90mm |
| RRU-QT-0402-H-C6..56-C | 40mm | 123mm |
| RRU-QT-0403-H-C6..56-C | 40mm | 123mm |
|
|
